Secure On-Line Order Form
ADVANCED Timber Framing: Joinery, Design & Construction of Timber Frame Roof Systems
ISBN-10: 1-889269-03-4 Hard Cover: 368 pages, over 900 4/C photos & illus. Cover Price: $75.00
Now in Stock for Immediate Shipment Add to Cart
A Timber Framer's Workshop:
This revised edition is a 272 page workbook that includes comprehensive in-depth technical information on the joinery, design and construction of Traditional Timber Frames. Illustrated with over 500 photos and CAD drawings, with over 150 new in this edition. Included are Frame Plans, design and engineering formulae, rule-of-thumb design and engineering guidelines, shop setup, builder's math, joinery design criteria, practical timber framing tips, tools and more. If you are an architect, engineer, builder or an aspiring owner builder wishing to build your own timber frame, A Timber Framer's Workshop will provide the information you need.
ISBN 1-889269-00-X Cover Price $35 Add to Cart
Special. Order both books for $99 save 10% Add to Cart
JQ SIX PACK (Your choice or ours of 6 back issues) $35 Add to Cart
JQ 12 pack (Your choice or ours of 12 back issues) $56 Add to Cart
JQ CASE (Your choice or ours of 24 back issues) $96 Add to Cart
JQ KEG (The whole set! 34 available issues) $115 Add to Cart
Gift Packs & Special Deals
1) Gift Pack: A Timber Framer's Workshop & A Timber Framing Mallet, $99 Add to Cart
2) Book Pack: A Timber Framer's Workshop & Advanced TF (book), $99
3) Gift Pack: A Timber Framer's Workshop (book) & JQ 4 Pack, $50
4) Gift Pack: JQ 4 Pack, T-shirt, A T.F. Workshop (book), $70
5) Gift Pack: JQ 6 Pack, A T.F. Workshop book, T.F Mallet, $130
6) Gift Pack: A TF Workshop (book), Advanced TF (book), TF Mallet, $165 Add to Cart
7) Gift Pack: Advanced TF book, #1218 Chappell Universal Square, $150 Add to Cart
8) Advanced T. F. book, #1824 Chappell Universal Square, $180
9) The Ultimate Gift Pack: JQ Keg,
The Chappell Universal Framing Square!!!
The Master Framer model #1824 and the Traveler model #1218 each have the unique, patented Chappell Universal Square rafter tables. The front side body has a comprehensive Equal Pitched Rafter Table for determining layout of hip and valley roof systems with common pitches ranging from 2/12 to 18/12. The front side tongues have Unequal Pitch Rafter Tables for unequal roof systems ranging from 4/12 to 15/12 with a main common pitch of 12/12. The back side bodies have comprehensive Rafter Tables for 6 and 8 sided polygons. The backside tongues have Unequal Pitch Rafter Tables for roof systems with a main roof of 9/12.
Made of 13 gauge stainless steel with deep etched rulings and tables, this square will last a lifetime. The Master Framer, model #1824 has a body 2" x24" and a tongue of 1-1/2" x 18". The Traveler, model #1218 has a body 2" x 18" and a tongue of 1-1/2" x 12".
Timber Framing Mallets
These mallets are hand turned from a variety of different hardwoods found in the San Luis Valley of Costa Rica, where we have been working with the local community for the past 10 years through our IPCBI workshop program. The mallets are hand turned by community members to the proper weight and balance to meet Fox Maple specs.
A good mallet will prevent fatigue and possible wrist injury that may arise from using a mallet not designed to meet the needs of heavy timber work with a framing chisel. The key is to hold the mallet lightly in hand and let the mallet do the work and not your arm or wrist. This requires the correct balance between handle thickness, length and weight. All of the mallets are hand-turned from a variety of tropical hardwoods species salvaged from dead tree limbs, old fence posts and even community members firewood piles.
Due to the varying density and weight of any specific wood specie, each mallet will vary in size, weight and length most suitable for the specific wood used. Sizes range from 16 to 18 inches in length, 2-1/2 to 3 inch head diameter and from 2.5 to 3 pounds. Because the wood is salvaged, some mallets may have slight blemishes as any recycled wood may have. Checks may also appear due to the change in climate, however, these will not affect the use or the life span of the mallet. Each mallet is essentially made to order, so please allow up to 3 to 4 weeks for delivery. For students planning to attend a Fox Maple workshop we recommend ordering at the time of registration and having it waiting for you when you arrive at the workshop. This will save shipping costs. $75 plus $12.95 S&H in US. Add to Cart
Copyright 2009-2012 Fox Maple Press, Inc. All rights reserved.
Scroll Down for More
• Timber Framing Mallets
• Chappell Square
• Gift Packs & Special Deals
Time Flies! 2013 marked
Fox Maple's 30th year of teaching
Perfection & Grace.
Advanced Timber Framing
June 6 - 11, 2016
Natural Building 2016
May 27 - 29, 2016
Cost Rica Winter 2016
Timber Framing Workshop
Nosara, Costa Rica
Feb. 22 - March 5, 2016
March 7 - 11, 2016
First Edition of
Advanced Timber Framing
At last, this long awaited book is now in stock and ready for immediate shipment.
This is a 368 page, hard cover volume that is jam packed with information about the design and construction of compound timber framed roof systems. From history to Design and Execution, Advanced
Timber Framing has it all covered.
Click cover graphic for more info
New Revised Edition
A Timber Framer's Workshop
This 272 pg. Revised Edition has over 150 new photos and includes updated engineering and comprehensive in-depth technical information on the joinery, design and construction of Traditional Timber Frames. Illustrated with over 500 photos and CAD drawings. Click on the book cover for more info or
Vive Jean-Claude T-Shirt:
(XXL add $2) $22.00 Add to Cart
All T's come in Navy Blue only, with White lettering. Vive Jean-Claude on the front, and Perfection & Grace on the back.
